Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Baosteel CRGO B20r070 Laser Scribed Silicon Steel

Baosteel CRGO B20r070 Laser Scribed Silicon Steel

Cold Rolled Grain Oriented Electrical Steel Sheet GRAIN-ORIENTED ELECTRICAL STEEL (CRGO) Grain oriented silicon steel sheet description As a Steel processing plant,all of our CRGO raw material is purchase from Baosteel,the biggest steel co in China,They offer expert-level products.
Types :Baosteel CRGO B20r070 Laser Scribed Silicon Steel
Thickness :0.20-0.65mm
Share:
Introduction
Major Manufacturer BAOSTEEL, WISCO, Nippon Steel, JFE, AK
Grade CRGO:
20ZDKH75, B20P075, B20P070, B18R070
B23G110, B23G100, B23P100, B23R095, B23R090, 23ZH90, 23QG090, B23R080
27Q120, 27QG100, 27QG095, B27P120, B27P100, B27P095
30Q130, 30Q120, 30QG105; B30G130, B30G120, B30P120, B30P105
35Q155, B35G155, 35Z155
CRNGO:
B35A270, B35A250, B35A230, B35A300, 35WW270, 35WW250, 35WW230
B50A800, B50A600, B50A470, B50A400, B50A310, B50A290, B50A250, B50A1300, B50A1000
Nominal thickness 0.18mm, 0.20mm, 0.23mm, 0.27mm, 0.30mm, 0.35mm, 0.5mm
Coil ID 508mm
Weight 2MT~8MT
Standard EN 10106, IEC 60404-8-4, ASTM, DIN, GB, JIS
Form Cold Rolled Strip
Delivery Lead Time 7~15 days after T/T prepayment or L/C date
Packing Standard export package for ocean transportation
Application All kinds of transformer, reactor, filter, inverter
Technical Data
Specification of CRGO silicon steel products
Type Grade Thickness (mm) Available width range(mm) ID Density (kg/dm³) P17/50Max. Core Loss(W/kg) B8Min. Induction(T)
Common Type B23G110 0.23 700-1200 508 7.65 1.10 1.80
B27G120 0.27 1.20 1.80
B30G120 0.30 1.20 1.80
B30G130 1.30 1.80
B30G140 1.40 1.80
B35G135 0.35 1.35 1.80
B35G145 1.45 1.80
B35G155 1.55 1.80
High Induction Type B23P090 0.23 0.90 1.87
B23P095 0.95 1.87
B23P100 1.00 1.87
B27P095 0.27 0.95 1.88
B27P100 1.00 1.88
B27P110 1.10 1.88
B30P100 0.30 1.00 1.88
B30P105 1.05 1.88
B30P110 1.10 1.88
B30P120 1.20 1.88
B35P135 0.35 1.35 1.88
B35P155 1.55 1.88
Domain Refined High Induction Type B23R080 0.23 0.80 1.87
B23R085 0.85 1.87
B23R090 0.90 1.87
B27R090 0.27 0.90 1.87
B27R095 0.95 1.87
NOTE:
Detecting Basis GB/T3655-2000
P17/50 means core loss of sample per kg at max. Magnetic induction 1.7T and frequency 50Hz
B8 means magnetic induction corresponding to 800A/m magnetic field intensity

Company advantage

Quality is guaranteed.
First, the raw materials come from many well-known domestic and foreign enterprises, such as Baosteel, WISCO, Nippon Steel. We have the most excellent materials.
Secondly, our company has a perfect quality assurance system, which guarantees that you can get the best products from purchase to delivery.

Price concessions.
Our company's product price is in the middle level of the industry, and is famous for its high cost performance. There is still a lot of room for price.
We look forward to your demand. We will give you a most suitable quotation.
