DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil
DC01 Cold Rolled Steel Coil

DC01 Cold Rolled Steel Coil

DC01 cold rolled steel coil. DC01 Cold rolled sheet coil are mainly used in automobile, printed metal pail, building, building materials, and bicycle, etc
Types :DC01 Cold Rolled Steel Coil
Thickness :0.12-5mm
Width :600mm--1500mm
Inside Diameter :508/610mm
Share:
Introduction

DC01 Cold rolled sheet coil application:
DC01 Cold rolled sheet coil is mainly used for deep drawing with a simple life supplies metal stamping parts, such as auto parts and electrical parts such as ductility demand higher product.

The grades are classified according to the maximum permissible yield strength and can be subdivided as follows.
DC01 – This grade can be used for simple forming work, for example Bending, embossing, beading and pulling are used.
DC03 – This grade is suitable for forming requirements such as Deep drawing and difficult profiles suitable.
DC04 – This quality is suitable for high deformation requirements.
DC05 – This thermoforming grade is suitable for higher forming requirements.
DC06 – This special deep drawing quality is suitable for the highest deformation requirements.
DC07 – This super deep drawing quality is suitable for extreme deformation requirements.

Product Description

Standard AiSi, ASTM, bs, DIN, GB, JIS
Grade DC01/DC02/DC03/DC04
Place of Origin China
  Anyang
Brand Name Gnee
Model Number DC01
Type Steel Coil
Technique Cold Rolled
Width 1250mm-2200mm
Length col
Tolerance ±1%
Type Cold Rolled Steel Sheet
Processing Service Bending, Welding, Decoiling, Cutting, Punching
Product Name Cold rolled coil DC01
chemical composition C ≤0.10 Mn≤0.50 S ≤0.025 P ≤0.035
Material DC01
MOQ 1 Ton
Coil Weight 3-8 Tons
Payment term L/C T/T (30% Deposit)
Delivery time 7-15 Days
Packing Standard Sea Worhty Packaging
Sample Sample Freely
Product Keywords DC01 cold rolled steel coil
Technical Data
Cold rolled steel according DIN EN 10130, 10209 and DIN 1623
Quality Testing direction Material-No. Yield point Rp0,2 (MPa) Tensile strength Rm (MPA) Elongation A80 (in %) min. r-Value 90° min. n-Value 90° min. Old Description
DC01 Q 1.0330 ≤280 270 - 410 28     St 12-03
DC03 Q 1.0347 ≤240 270 - 370 34 1,30   St 13-03
DC04 Q 1.0338 ≤210 270 - 350 38 1,60 0,18 St 14-03
DC05 Q 1.0312 ≤180 270 - 330 40 1,90 0,20 St 15-03
DC06 Q 1.0873 ≤170 270 - 330 41 2,10 0,22
DC07 Q 1.0898 ≤150 250 - 310 44 2,50 0,23

Quality Testing direction Material-No. Yield point Rp0,2 (MPa) Tensile strength Rm (MPA) Elongation A80 (in %) min. r-Value 90° min. n-Value 90° min.
DC01EK Q 1.0390 ≤270 270 - 390 30
DC04EK Q 1.0392 ≤220 270 - 350 36
DC05EK Q 1.0386 ≤220 270 - 350 36 1,50
DC06EK Q 1.0869 ≤190 270 - 350 38 1,60
DC03ED Q 1.0399 ≤240 270 - 370 34
DC04ED Q 1.0394 ≤210 270 - 350 38
DC06ED Q 1.0872 ≤190 270 - 350 38 1,60

Quality Testing direction Material-No. Yield point Rp0,2 (MPa) Tensile strengthRm (MPA) Elongation A80 (in %) min. DIN 1623 T2 (old)
S215G Q 1.0116G ≥215 360 - 510 20 St 37-3G
S245G Q 1.0144G ≥245 430 - 580 18 St 44-3G
S325G Q 1.0570G ≥325 510 - 680 16 St 52-3G

Cold Rolled Steel Coil
Cold rolled steel is also part of our product portfolio. Cold rolled steel is excellent for cold forming. This product group assigned the grades DC01 to DC07, DC01EK to DC06EK, DC03ED to DC06ED and S215G to S325G.

We can meet our customer's any quantity request. Our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
